CJ-180
|
|
|
Model
|
8740ADE
|
|
Print head
|
Piezoelectric print head DX7
|
|
Number of print head
|
Two Heads
|
|
Max mum Print Width
|
1880mm(74”)
|
|
Printing Resolution
|
720X360 720X720 1440X1440(dpi)
|
|
Printing Resolution
|
4pass
|
4m2/hr
|
|
6pass
|
24m2/hr
|
|
8pass
|
18m2/hr
|
|
16pass
|
9m2/hr
|
|
Ink
|
Type
|
Eco-Solvent Ink
|
|
Color
|
Double 4 colors
|
|
Capacity
|
440ml of each ink cartridge
|
|
Ink Supply System
|
Block brake type of ink supply system
|
|
Media
|
Width
|
1880mm(74”)
|
|
Type
|
Canvas paper car stick, reflective material ,etc
|
|
Print head Height
|
Above Media Adjustable
|
|
Heating system
|
Intelligent embedded heating system
|
|
Media adsorption system
|
Several phase of intelligent air draft and intensity adjustable
|
|
Auto Media system
|
Heavy-duty hydraulic damping type
|
|
Auto Cleaning of Print head
|
Intelligent cleaning system
|
|
Auto paper collecting system
|
Optional
|
|
Print Interface
|
USB2.0
|
|
RIP software
|
Maintop 、Photo print 、Wasatch
|
|
Input Power
|
AC220V,50Hz/60Hz
|
|
Machine Dimension
|
2855X650X700mm(LxWxH)
|
|
Package Dimension
|
2900X970X750mm(LxWxH)
|
